UNUSED Lot of 6 Thermo Scientific APEX 500 Pharmaceutical Metal Detector
Manufacturer : Thermo Scientific
Model : APEX 500 Rx
Construction year : 2012
State : like new
Status : other status
Location : Ukraine
Reference : PRO3118

Unused Lot of 6 Thermo Scientific APEX 500 Rx Metal Detector

General Specifications from manufacturer:
Construction: Stainless steel 304 straightlined case, high polish optional. All plastics used are FDA approved.
Protection Ratings: Type 3 enclosure, metal detector and control panel only
Relative Humidity: 20% to 80% non-condensing
Electrical Supply: 85 volts to 260 volts AC single phase plus earth ground; 47 Hz to 65 Hz, 100 watts maximum
Air Supply: 5.5 bar (80 psi) nominal, 4 bar (60 psi) minimum – for AuditCheck and/or pneumatic rejector (not required for electronic rejecter)
Product Speed: 0.5 m/min (1.7 ft/min) to 100 m/min (330 ft/min) for the system
Outputs: 6 Relays outputs; Relays: 250 volt AC 2 amp max. 50 volt DC 1 amp max.
Output Allocation: Reject 1, Reject 2, AuditCheck, Fault, Alarm, Warning, QAT lamp (selectable via menu)
Inputs: 6 Inputs – Active 12v DC 12 volt auxiliary supply for input sensors
Input Allocation: Speed Sensor, Keylock, Product Select 1, Product Select 2, Infeed PEC, Reject Confirmation 1 and Bin Full External
Suppression, Reject 1 Complete, Clear All Warnings/Alarms/Faults (selectable via menu), External Alarm, External Reset
Communications: Optional Modbus serial or Ethernet modules
Safety and Export Approvals: cCSAus, CE
Manufacturing Quality: ISO9001 certified

Year    2012
Model    APEX 500
CE Marked    YES
Products Run    tablets and capsules
Voltage    220 VOLT
Frequency    50 HERTZ
Recommended Packaging Form    CUSTOM
Estimated Shipping Weight    221 lb    100 KGS
Estimated Shipping Length    25 in    635 MM
Estimated Shipping Width    19 in    460 MM
Estimated Shipping Height    49 in    1235 MM

Features & Benefits
– Cost-effective solution for tablet presses,capsule filling and deduster applications
– Straight through product flow to prevent product damage
– High sensitivity—can detect pieces of metal as small as 0.3 mm
– Improves productivity with throughput up to 500K tablets or capsules per hour
– Easy to use—features graphical user interface (GUI) that uses a durable touch-sensitive keypad
– Assists in compliance with GMPs in 21 CFR part 210 and 211
– Available as a complete system, OEM module or head and control panel only
